Optical Scanning
Our SSR family of scan motor/controllers provide constant speed rotation of polygon mirrors, prisms, or other payloads for optical and laser scanning applications. These scan motors do not include the mirror or payload. Polygon mirrors or other payloads can be supplied to your specifications.
A rotary transformer option is available on the SSR2300 which provides power and communication to an active E/O payload. The rotary transformer provides a reliable, non-contact alternative to slip ring circuits. For details, please see the SSR2300 data sheet.
The selection table below list some of the key features of each product. Please click on the model number for additional information and downloadable drawings.
A rotary transformer option is available on the SSR2300 which provides power and communication to an active E/O payload. The rotary transformer provides a reliable, non-contact alternative to slip ring circuits. For details, please see the SSR2300 data sheet.
The selection table below list some of the key features of each product. Please click on the model number for additional information and downloadable drawings.
| Model |
Max Payload Size |
Speed Range |
Speed Stability |
Encoder Output |
Rotary Transformer Option |
Controller Driver Included |
Ext/Int Speed Reference |
| SSR2300 |
3” X 3” |
30 - 4000 RPM |
0.001% |
A, B, Index |
Y |
Y |
Y |
| SSR1700 |
3” X 1” |
300 – 5000 RPM |
0.001% |
A, B, Index | N |
Y |
Y |
| SSR1300 |
2” X 1” |
300 – 5000 RPM |
0.01% |
Hall Sensor |
N |
Y |
Y |
| SSR1100 |
1.5” X 0.5” |
1000 – 10000 RPM |
0.01% |
Hall Sensor |
N |
Y |
Y |
The SMP3010 Fast Mirror Positioner is designed to provide high speed angular positioning of mirrors, prisms, or other payloads for optical and laser beam steering applications. Random or repetitive motion is supported. Angular range is either +/-30 or 360 degrees depending on the feedback device selected. Feedback device options include RVDT, resolver, and optical encoder.
The positioner does not include the mirror or payload. Metal or glass mirrors, as well as other payloads may be supplied to customer specifications.
The positioner does not include the mirror or payload. Metal or glass mirrors, as well as other payloads may be supplied to customer specifications.
